Solving GATE EC MCQ, MSQ and NAT questions months before the examination will help you analyze your preparation and guarantee 80+ marks in Electronics and Communications paper. The probable GATE EC sample questions provided here are based on numerical problems and core concepts.
GATE EC MCQ, MSQ and NAT Questions: Students appearing for the GATE ECE exam 2025 must attempt various practice questions after completing syllabus. It’s important that you practically solve GATE EC MCQ, MSQ and NAT questions rather than just studying theoretically. Practicing with the GATE ECE model questions will help you analyze your preparation and find out your shortcomings whether you are forgetting formulae or not remembering the concepts. By solving the imposrant GATE EC MSQ questions you will improve your preparation. GATE 2025 exam for EC will have 3 sections, namely Engineering Mathematics, General Aptitude, and Core Electronics and Communication Engineering subjects. The General Aptitude part has 15 marks weightage and Engineering Mathematics and Core ECE subjects combined have 85 marks weightage in the GATE exam 2025. You can check out the GATE NAT questions for Electronics and Communication Engineering on this page.
Quick Links:
| GATE 2025 Admit Card | GATE 2025 Exam Preparation Tips |
|---|---|
| Best Books for GATE 2025 Exam Preparation | GATE 2025 Exam Dates |
Most Important GATE EC MCQ, MSQ and NAT Questions
Electronics and Communication Engineering (EC) is one of the most opted papers in the GATE examination which makes it tough to score the cutoff marks. However, with proper exam preparation and thorough practice of GATE EC MCQ, MSQ and NAT questions you can ace the exam with good scores. According to the GATE 2025 exam pattern , the paper will have NAT, MCQ, and MSQ questions. You must practice all sorts of questions to prepare well for the GATE ECE exam. Attempt the following GATE EC MCQ questions taken from the GATE previous year question papers .
Network Theory
Q1- Norton's theorem states that a complex network connected to a load can be replaced with an equivalent impedance...
A- in series with a current source
B- in parallel with a voltage source
C- in series with a voltage source
D- in parallel with a current source
Answer- Option D is correct
Q2- For parallel RLC circuit, which one of the following statements is NOT correct?
A- The bandwidth of the circuit decreases if R is increased
B- The bandwidth of the circuit remains same if L is increased
C- At resonance, input impedance is a real quantity
D- At resonance, the magnitude of input impedance attains its minimum value.
Answer- Option D is correct
Control Systems
Q3- Match the following with List-1 with List-2
List-1
(a) Very low response at very high frequencies
(b) Overshoot
(c) Synchro-control transformer output
List-2
(1) Low pass systems
(2) Velocity damping
(3) Natural frequency
(4) Phase-sensitive modulation
(5) Damping ration
Answer- Correct answer is (a) - (1) , (b) - (5) , (c) - (4)
Q4- The Nyquist stability criterion and the Routh criterion both are powerful analysis tools for determining the stability of feedback controllers. Identify which of the following statements is FALSE.
A- The closed-loop frequency response for a unity feedback system cannot be obtained from the Nyquist plot.
B- The Routh criterion is not applicable in the condition of transport lag, which can be readily handled by the Nyquist criterion.
C- The general shape of the Nyquist plot is readily obtained from the Bode magnitude plot for all minimum-phase systems.
D- Both the criteria provide information relative to the stable gain range of the system.
Answer- Option A is correct
Quick Links:
| GATE 2025 Exam Centers | GATE Sample Papers |
|---|---|
| GATE 2025 Mock Test | Best GATE Coaching Institutes in India 2025 |
Electronic Devices and VLSI
Q5- In a semiconductor, if the Fermi energy level lies in the conduction band, then the semiconductor is known as:
A- degenerate n-type
B- degenerate p-type
C- non-degenerate n-type
D- non-degenerate p-type
Answer- Option A is correct
Q6- A region of negative differential resistance is observed in the current voltage characteristics of a silicon PN junction if:
A- Both the P-region and the N-region are heavily doped
B- The N-region is heavily doped compared to the P-region
C- The P-region is heavily doped compared to the N-region
D- An intrinsic silicon region is inserted between the P-region and the N-region
Answer- Option A is correct
Analog Circuit
Q7- Match the following:
GROUP-1
(A) Hartley
(B) Wein-bridge
(C) Crystal
GROUP-2
(1) Low frequency oscillator
(2) High frequency oscillator
(3) Stable frequency oscillator
(4) Relaxation oscillator
(5) Nagative Resistance oscillator
Answer- Correct answer is (A)-(2), (B)-(1), (C)-(3)
Q8- The Miller effect in the context of a Common Emitter amplifier explains
A- an increase in the low-frequency cutoff frequency
B- an increase in the high-frequency cutoff frequency
C- a decrease in the low-frequency cutoff frequency
D- a decrease in the high-frequency cutoff frequency
Answer- Option D is correct
Signals and Systems
Q9- Rectangular pulse of duration T is applied to a filter matched to this input. The output of the filter is a:
A- rectangular pulse of duration T.
B- rectangular pulse of duration 2T.
C- triangular pulse.
D- sine function.
Answer- Option C is correct
Q10- Consider the following statements for continuous-time linear time invariant (LTI) system.
I. There is no bounded input bounded output (BIBO) stable system with a pole in the right half of the complex plane.
II. There is no causal and BIBO stable system with a pole in the right half of the complex plane.
Which one among the following is correct?
A- Both I and II are true
B- Both I and II are not true
C- Only I is true
D- Only II is true
Answer- Option D is correct
What are GATE EC MCQ, MSQ and NAT Questions?
The GATE 2025 exam will include majorly 3 types of questions, ie, MCQ, MSQ, and NAT. All of these questions will have a different format and the answering process of the same will also be dissimilar. The points below entail the crux related to GATE EC MCQ, MSQ and NAT questions:-
- MCQs: Shortened for Multiple Choice Questions, they will include 4 options, out of which, one will be correct. Choosing the correct option will win you a mark, however, choosing the incorrect answer will lead to negative marking.
- MSQ: The GATE exam will have various Multiple Select Questions wherein, various options will be correct. In order to be awarded a mark, you will have to choose all the correct answers. You should note that the authority does not follow negative markings for MSQs.
- NAT: The Numerical Answer Type questions are the numerical problems that typically have answers in decimal form. There will be no negative marking in the NAT questions.
GATE EC MCQ, MSQ and NAT Questions Marking Scheme
The marks in the GATE 2025 EC exam will be awarded as per the marking scheme. As the exam taker of GATE, you should be well versed with the marking scheme. You can find the detailed GATE EC MCQ, MSQ and NAT questions marking scheme below:-
Types of Questions | Marking Scheme |
|---|---|
MCQ |
|
NAT | No negative marking |
MSQ | No negative marking |
Electronics and Communication Engineering papers will have numerical questions, so improve your Mathematics and learn the formulae. The GATE 2025 syllabus PDF for ECE also consists of theoretical topics that you must study thoroughly to understand the concepts. The best way to qualify the GATE ECE exam with flying colors is to practice questions from previous year papers, test series, sample papers, and mock tests. We wish you all the best for your exam!
Quick Links:
Related Articles
We hope that this post on the GATE MCQ for Electronics & Communication Engineering was helpful and informative.For more information stay tuned to CollegeDekho!
Are you feeling lost and unsure about what career path to take after completing 12th standard?
Say goodbye to confusion and hello to a bright future!
FAQs
The GATE Electronics and Communication Engineering exam 2025 will be held for a total of 100 marks and includes 65 questions.
No, along with solving the GATE Electronics and Communication Engineering model questions also attempt previous year papers, mock tests, sample papers, test series, and other important questions that you find online.
Solving the GATE ECE model questions will help you understand your exam preparation and work on your shortcomings.
Yes, the GATE Electronics & Communication Engineering paper is tough as many students appear for it and the cutoff is set high by the authorities. However, with solid exam preparation, practicing various questions from previous year papers, and mock tests you can pass the GATE ECE exam. Remember, revision of the complete syllabus is also important.
The GATE 2025 ECE exam will be held on February 2, 2025.
