GATE 2024 Mechanical Question Paper : The IISc, Bengaluru is conducting the GATE Mechanical Engineering 2024 examination today, February 3, 2024 , in the second shift. Shift 2 began at 2:30 PM and will conclude at 5:30 PM . The memory-based questions from the Mechanical paper will be shared here, as and when received from the applicants. Examinees can submit the questions that they remember in the Google form link below. The question paper of GATE Mechanical 2024 comprises 65 questions, 10 from General Aptitude, and 55 from Mechanical Engineering and Engineering Mathematics. Multiple-choice questions, multiple-select, and numerical answer type questions are being asked in the test. All MCQ and MSQ questions comprise 1 mark each, and NAT questions comprise 2 marks. The total marks combining both the segments in 100.
Have you appeared for the GATE 2024 ME exam? | Click Here to Submit Questions |
---|
GATE Mechanical Question Paper 2024 PDF
Based on the responses submitted by the examinees after the examination, the unofficial GATE Mechanical 2024 question paper will be shared here. You can also check the GATE Mechanical 2024 Answer Key .
Coaching Institute Name | PDF Link |
---|---|
Physics Wala | Click Here |
GATE ME 2024 General Aptitude Questions
A total of 10 questions appeared from this segment; 5 questions were for 1 mark, and 5 for 2 marks each, totalling 15 marks. Check out the memory-based questions from General Aptitude here.
- Among the given series 1, 1, 2, 3, 6, 8, 13, 21, which number is not in pattern
GATE Mechanical Marks vs Rank Analysis 2024 | GATE Mechanical Raw Score vs Scaled Score 2024 |
---|---|
GATE ME Exam Analysis 2024 | GATE Mechanical (ME) Expected Qualifying Cutoff Marks 2024 |
GATE 2024 Mechanical Subject-Specific Questions
A total of 55 questions appeared from this segment; 25 questions were for 1 mark, and 30 for 2 marks each, totalling 85 marks. Check out the memory-based questions from Mechanical Engineering and Engineering Mathematics here.
- Find the diameter of the punch where the diameter of the blank is 20 meters (Blanking Operation) and clearance = 0.04 mm
- What will be the maximum amount of work done from the thermodynamic system W max . If Q = 24000 KiloJ/min, Temprature = 1200 Kelvin, T o = 300 k
- Among the given options which is the most conservative theory (Solderberg, Goodman, yield, Kohlberg)
-
From the given date find t
3
1 V = 60 m/min 1 t = 60 min V 2 = 100 m/min t 2 = 10 min V 3 = 80 m/min t 3 = ? min - The grinding wheel is used to produce the best surface finish
- A three-hinge arch ABC in the form of a semi-circle is shown in the figure. The :in static equilibrium under vertical loads P = 100 kN and Q = 50 kN. Neglectat all the hinges. The magnitude of horizontal reaction at B is__KN. [Correctdecimal place]
- A rigid massless tetrahedron is placed such that vertex D is at the origin and the other three vertices A. B and C lie on the coordinate axes as shown in the figure. The body is acted on by three point loads of which one is acting at A along x-axis and the other at point B along y-axis. For the body to be in equilibrium, the third point load acting at point O must be
- A ram in the form of a rotating body of size 1 = 9 m and b = 2 m is suspended by two parallel ropes of lengths 7 m. Assume the centre of mass of the body is at its geometric centrer and g = 9.81 m/s 2 . For striking the object P with with horizontal velocity of 5 m/s, what is the angle (theta) with the vertical from which the ram should be released from rest?
- A linear spring-mass-dashpot-system with a mass of 2 kg is set in motion with viscous damping. If the nature frequency is 15 Hz, and the amplitude of two successive cycle measured are 7.75 mm and 7.20 mm, the coefficient of viscous damping in (Ns/m) is
