ITI Advanced CNC Machining Technician Syllabus: Semester-wise Syllabus, Eligibility Criteria

ITI Advanced CNC Machining Technician Syllabus: Are you planning to apply for the ITI Advanced CNC Machining Technician program? Then it’s important to understand the syllabus. The syllabus lists the topics covered in the course, helping students plan their studies. Students should review the syllabus closely to grasp the course content.

The Advanced CNC Machining Technician course lasts two years and is available nationwide through a network of ITIs. The program includes two main parts: the Domain area and the Core area. The Domain area covers trade theory and practical skills, providing professional knowledge. The Core area focuses on employability skills and essential life skills. After completing the training, trainees receive a National Trade Certificate (NTC) from DGT, recognized worldwide. Students can also find the official ITI Advanced CNC Machining Technician syllabus in the brochure - Official ITI Advanced CNC Machining Technician Syllabus PDF

Course Structure of Advanced CNC Machining Technician

Here’s the training hours distribution for the Advanced CNC Machining Technician course over the two years:

Every year, students must complete 150 hours of On-the-Job Training (OJT) at a local industry. If OJT is not available, trainees must work on a group project instead.

Students can also take optional courses totalling up to 240 hours each year. These courses can help them earn a certificate for 10th or 12th grade, ITI certification or short-term courses.

Detailed ITI Advanced CNC Machining Technician Syllabus

History and development of CNC technology: Different types of milling machine configurations, such as horizontal, vertical, Knee type, and universal head type; different types of Tools used and clamping method; fundamentals of Cutting speed and feed; identification of worn-out tools.

Fundamentals of workpiece rotation: Three jaw/four jaw chucks/face plate clamping of workpiece. Tool post, tail stock, and its setting are used to adjust the taper. Centre height adjustment of Tool Orientation of simple turning operation. Inspection quality of the product by using measuring instruments like Vernier, micrometre etc.

Knowledge of unconventional machining operations: Abrasive jet machining (AJM), Ultrasonic machining (USM), Electro-chemical machining (ECM), Plasma ARC machining, (PAM)Laser-Beam machining (LBM)

Introduction to product design and development: Customer’s requirements & specifications. Importance of customer relationship management.

Introduction to engineering drawing: Fundamentals of limits fits & tolerances & symbols—importance of interchangeability & ISO standards. Understand industrial Engineering special Characteristic symbols, Customer-specific standards drawing and notation, geometrical dimensions & tolerances. Symbols used in industrial machining drawings include surface finish, machining operation, surface treatment, GD&T, etc.

Introduction to machining procedure: From raw material to finished product. Concept of the process flow of machining operation. Concept Work-piece holding. Importance of multi-stage drawing.

Introduction to surface finish and its importance: International standards & symbols used to represent surface finish Concept of surface finish calculation of Ra, Rt, Rz, R3z, etc. Introduction to improve surface finish quality. Introduction of post-process manufacturing operation to improve surface finish quality.

Introduction to product quality: Concept of quality control & quality assurance. Introduction to inspection Instruments. Importance of calibration of inspection instruments. Inspection instrument handling Standard guidelines/procedure to minimise human error. Concept of inspection instruments Gage Repeatability and Reproducibility (Gage R & R) Types of inspection reports.

Understand the cutting tools, holders & types: Nomenclature of cutting tools & their machining process parameters. Selection of cutting tools & Holders Cutting fluid & its importance Selection of cutting fluid & coolant used for machining. Concept of workpiece holding devices and references. What are work-piece holding devices, Understand the Jigs & fixture

Introduction industrial evolution: Introduction to CNC machine working principle. History & development of CNC technology. Conventional Vs. non-conventional machine tools. Concept of Numerical control on CNC machine tools and CNC Control.

Introduction to G&M code: Introduction to G code, Introduction to M code Concept of block number, end of block.

Introduction to computer-aided manufacturing software: Learn all its syntax. Open/modify a file in CAM software. Concept of toolbar and ribbon Setting attribute and user interface orientation.

Import the 3D model: Start machine simulation in Computer Aided Manufacturing Software. Simulate Computer. Aided Manufacturing Software. Generate the NC Program. Export the NC program for machining

Introduction to manufacturing processes: Concept of machining a component & its process. Design concept in the assembly of parts, its tolerances mentioned in drawing to perform the designed task. Introduction to CNC lathe & VMC milling machine. Concept of NC machine controllers (Fanuc, Sinumeric, Mitsubishi, etc.) Importance Emergency stop key on the machine.

Concept of CNC turning centre over travel limits: Importance Emergency stop function key. Concept of CNC turning centre mode like Jog, MDI, Edit, Auto, Single Block, MPG.

Concept of sub-programming: Concept of block in CNC turning programming.

Introduction to advanced CNC: Turning Centre Programme, Selection of Tools depending on the material to be cut. Concept of G Codes and M Codes used in machine programming. Program creation tools & techniques. Generation of complex machining part program with the help of advanced CAM software. Tool path optimisation Cycle time calculation. Machine offset Cutter tool nose radius Compensation. Concept of Interpolation and Canned Cycles.

Concept of tool nose radius compensation: Its impact on the shape of part & cutting tool life. Explain codes used for Tool nose radius compensation.

Concept of live tool & set up: Concept of Drilling cycle, spot boring cycle. Concept of canned cycle & wood picking cycle.

Concept & impact of absolute programming: Concept of Incremental programming in CNC turning program.

Basic maintenance of VMC and turning machine: Preventive maintenance. Basic troubleshooting of CNC machine Introduction to TPM (Total Productive Maintenance)

Learning Outcomes of Advanced CNC Machining Technician Trade

Following is a list of skills and lessons that students will learn during the Advanced CNC Machining Technician:

• Follow safety and environmental guidelines, and maintain a clean workspace.
• Operate milling machines and perform basic turning operations on simple parts.
• Use unconventional machining processes and identify customer needs and specifications.
• Read and understand industrial engineering drawings and create detailed machining drawings.
• Check surface finish quality and inspect final product quality using appropriate measuring tools.
• Identify cutting tools and proper work-holding techniques, and perform both conventional and CNC manufacturing processes.
• Use M and G codes for CNC and VMC machines while creating and handling computer-aided machining models.
• Verify tool path generation using CAM software and explain the need for CNC turning and VMC machines.
• Describe the benefits of advanced CNC turning centres and operate them, understanding their various modes.
• Program and run CNC programs, including creating linear and circular interpolation programs with tool nose radius compensation.
• Carry out preventive maintenance and basic troubleshooting of CNC turning centres.
• Apply engineering drawings and use basic math concepts relevant to practical tasks in the field.

ITI Advanced CNC Machining Technician Eligibility Criteria

Students interested in pursuing a diploma in ITI Advanced CNC Machining Technician course must have at least a class 10th qualification. ITI's Advanced CNC Machining Technician trade eligibility criteria are listed below:

• Passed 10th Class (recognised board and institute)
• students must be able to speak both English and Hindi fluently.

Related Reads:

We hope this article has provided important information about jobs related to Advanced CNC Machining Technicians. To excel in the ITI Advanced CNC Machining Technician, it's essential to understand the syllabus. Create a study plan to cover all topics and ensure you practice and revise regularly to master the concepts.
